Hyper scale AI Data Center:
Rack/Stack and Structured
Cabling
Client Overview
Brainotech IT Solutions delivered a high‑density GPU cluster with a strong emphasis on disciplined rack‑and‑stack, resilient UPS/PDU design and production‑grade cabling (fiber and Cat6A). Scope covered fabric‑ready structured cabling, dual‑feed power architecture and formal cable certification using Fluke test instruments.
Business Challenge
The pilot rack exhibited intermittent link errors and lacked structured, fabric‑ready cabling. The new build required:
- Clean, repeatable rack and‑stack at scale.
- 2×100G fabric readiness with clear separation between fabric & management.
- Resilient dual‑feed power via UPS and intelligent PDUs.
- End‑to‑end copper and fiber certification without extending time to production.
Our Solution
1: Rack & Stack and Fabric Readiness connectivity
- Racked eight high‑density cabinets with GPU servers, storage and spine/leaf switches.
- Implemented standardized elevations and labelled RU plans to streamline access.
- Layered cabling by function (fabric & management) with defined pathways
2. Cabling (Fiber and Cat6A)
- Structured cabling with pre‑terminated trunks and modular panels; labelling ports, panels and trunks.
- Fiber: OM4; MPO trunks with Type‑B polarity for 100G.
- Copper: Cat6A for management and storage control paths; short, color‑coded patch leads
3. Power Architecture: UPS & PDUs
- Dual independent power feeds per rack via the UPS, each landing on intelligent three‑phase PDUs with per‑outlet metering.
- Exercised failover across fabric and storage tiers to validate resilience and recovery behaviour.
- Color‑coded armored power cords and locking IEC connectors; end‑to‑end power chain documentation down to the outlet.
4: Cable Testing & Certification Copper (Cat6):
- Certified Permanent Links with Fluke Networks DSX‑8000 Cable Analyzer
- Verified ACR‑F, return loss, propagation delay and length; saved results to LinkWare and
provided PDF to customer.
5: Cable Testing & Certification Copper (Cat6A):
- Tier 1 (Basic) certification using Fluke CertiFiber Pro OLTS.
Outcomes
- Production‑ready in 8 business days. 62% decrease in CRC/errored frames after structured cabling and certification.
- Predictable single‑feed failover with ≤5% performance deviation under test.
- Delivered a complete runbook with rack elevations and certification reports.
